ALWAYS IN STYLE.
A quintessential American cruiser, the Harley-Davidson Heritage Classic 114 has showstopping vintage details and pure rock ‘n’ roll style.
Upright riding position
Floorboards
Passenger seat
Saddlebags
Detachable windshield
LENGTH | 2,415 mm |
SEAT HEIGHT, UNLADEN | 680 mm |
GROUND CLEARANCE | 120 mm |
RAKE | 30 |
TRAIL | 140 mm |
WHEELBASE | 1,630 mm |
TYRES, TYPE | Dunlop™ Harley-Davidson Series, bias blackwall front and rear |
TYRES, FRONT SPECIFICATION | 130/90B16,73H,BW |
TYRES, REAR SPECIFICATION | 150/80B16,77H,BW |
FUEL CAPACITY | 18.9L |
OIL CAPACITY (W/FILTER) | 4.7L |
WEIGHT, AS SHIPPED | 316 kg |
WEIGHT, IN RUNNING ORDER | 330 kg |
Engine | Milwaukee-Eight™ 114 |
Bore | 102 mm |
STROKE | 114.3 mm |
DISPLACEMENT | 1,868 cc |
COMPRESSION RATIO | 10.5:1 |
FUEL SYSTEM | Electronic Sequential Port Fuel Injection (ESPFI) |
EXHAUST | 2-into-2 staggered; catalyst in muffler |
ENGINE TORQUE TESTING METHOD | EC 134/2014 |
ENGINE TORQUE\xA03 | 155 Nm |
ENGINE TORQUE (RPM) | 3000 |
HORSEPOWER | 93 HP / 69 kW @ 5020 rpm |
LEAN ANGLE, RIGHT (DEG.) | 27.3 |
LEAN ANGLE, LEFT (DEG.) | 28.5 |
FUEL ECONOMY TESTING METHOD | EU 134/2014 |
FUEL ECONOMY | 5.5 l/100 km |
PRIMARY DRIVE | Chain, 34/46 ratio |
GEAR RATIOS (OVERALL) 1ST | 9.311 |
GEAR RATIOS (OVERALL) 2ND | 6.454 |
GEAR RATIOS (OVERALL) 3RD | 4.793 |
GEAR RATIOS (OVERALL) 4TH | 3.882 |
GEAR RATIOS (OVERALL) 5TH | 3.307 |
GEAR RATIOS (OVERALL) 6TH | 2.79 |
FRONT FORK | Dual-bending valve 49 mm telescopic with aluminum fork triple clamps; dual rate spring |
REAR SHOCKS | Hidden, free piston, coil-over monoshock; 43mm stroke; toolless hydraulic preload adjustment |
WHEELS, OPTIONAL STYLE TYPE | Black or chrome, steel laced (based on trim) |
WHEELS, FRONT TYPE | Black or chrome, steel laced (based on trim) |
WHEELS, REAR TYPE | Black or chrome, steel laced (based on trim) |
BRAKES, CALIPER TYPE | 4-piston fixed front and 2-piston floating rear |
BRAKES, ROTOR TYPE | Solid, uniform expansion rotors |
LIGHTS (AS PER COUNTRY REGULATION), INDICATOR LAMPS | All LED, low beam, high beam and signature position lamp; Integrated, multi-function LED stop/tail/turn signals; Incandescent bullet turn signals; Integrated, multi-function LED stop/tail/turn signals |
GAUGES | 5-inch analog speedometer with digital gear, odometer, fuel level, clock, trip, range and tachometer indication |
ANTI-LOCK BRAKE SYSTEM (ABS) | Included |
