FULLY LOADED AND UNINHIBITED.
The Harley-Davidson Tri Glide Ultra is a long-haul touring Trike with all the torque, style, premium infotainment, and cargo space you’ll ever need.
Upright riding position
Floorboards
Passenger seat with backrest
Trunk
Frame mounted fairing
Rider safety enhancements available
LENGTH | 2,670 mm |
SEAT HEIGHT, UNLADEN | 735 mm |
GROUND CLEARANCE | 125 mm |
RAKE | 26 |
TRAIL | 100 mm |
WHEELBASE | 1,670 mm |
TYRES, TYPE | Dunlop™ Harley-Davidson Series, bias blackwall front and radial blackwall rear |
TYRES, FRONT SPECIFICATION | MT90B16 72H |
TYRES, REAR SPECIFICATION | P205/65R15 92T |
FUEL CAPACITY | 22.7L |
OIL CAPACITY (W/FILTER) | 4.7L |
WEIGHT, AS SHIPPED | 544 kg |
WEIGHT, IN RUNNING ORDER | 561 kg |
LUGGAGE CAPACITY -VOLUME | 0.19 m3 |
Engine | Twin-Cooled™ Milwaukee-Eight™ 114 |
Bore | 102 mm |
STROKE | 114.3 mm |
DISPLACEMENT | 1,868 cc |
COMPRESSION RATIO | 10.5:1 |
FUEL SYSTEM | Electronic Sequential Port Fuel Injection (ESPFI) |
EXHAUST | Shorty slash down-style chrome finish mufflers |
ENGINE TORQUE TESTING METHOD | EC 134/2014 |
ENGINE TORQUE\xA03 | 159 Nm |
ENGINE TORQUE (RPM) | 3000 |
HORSEPOWER | 87 HP / 65 kW @ 5020 rpm |
FUEL ECONOMY TESTING METHOD | EU 134/2014 |
FUEL ECONOMY | 6.8 l/100 km |
PRIMARY DRIVE | Chain, 34/46 ratio |
GEAR RATIOS (OVERALL) 1ST | 10.534 |
GEAR RATIOS (OVERALL) 2ND | 7.302 |
GEAR RATIOS (OVERALL) 3RD | 5.423 |
GEAR RATIOS (OVERALL) 4TH | 4.392 |
GEAR RATIOS (OVERALL) 5TH | 3.741 |
GEAR RATIOS (OVERALL) 6TH | 3.157 |
FRONT FORK | 49 mm Dual Bending Valve |
REAR SHOCKS | Hand-adjustable emulsion rear suspension |
WHEELS, FRONT TYPE | Black, 7-spoke Cast Aluminum |
WHEELS, REAR TYPE | Black, 7-spoke Cast Aluminum |
BRAKES, CALIPER TYPE | Front: 32 mm 4 piston fixed, Rear: floating 36mm piston integrated park brake |
BRAKES, ROTOR TYPE | Dual floating rotors (front), fixed rotor (rear) |
LIGHTS (AS PER COUNTRY REGULATION), HEADLAMP, TAIL/STOP/FRONT SIGNAL LIGHTS | LDual halogen headlight 55-watt 625 lumen low beam, 65-watt 1,570 lumen high beam; LED tail/stop, front signal lights and rear turn signals |
GAUGES | Speedometer, tachometer, fuel, and voltage gauges; display features odometer, trip A, trip B, range to empty, gear indicator |
INFOTAINMENT SYSTEM | Boom!™ Box GTS |
SCREEN SIZE | 165 mm |
TYPE | Full Color TFT |
WATTS PER CHANNEL | 25 |
SPEAKERS | 4 |
SPEAKER SIZE | 5.25 inch standard |
HEADSET SPECIFICATIONS (IF EQUIPPED) | 16 - 64 ohms |
AM | Standard |
FM | Standard |
SD CARD, FLASH DRIVE AND MP3 - VIA USB CONNECTION | Supported |
LANGUAGES | Arabic, Bahasa (Indonesian), Catalan, Chinese (Simplified/Traditional), Czech, Danish, Dutch, English (UK/USA default), Finnish, French (Canada/France), German, Hebrew, Hungarian, Indonesian, Italian, Japanese, Korean, Malay, Norwegian, Polish, Portuguese (Brazil/Portugal), Romanian, Russian, Siamese (Thai), Slovak, Spanish (Mexico/Spain), Swedish, Tagalog, Turkish, Vietnamese |
HANDS-FREE MOBILE PHONE - VIA BLUETOOTH | Standard |
VOICE RECOGNITION LANGUAGES: PHONE FUNCTIONS ONLY | Phone dependent |
VOICE RECOGNITION LANGUAGES: TUNER/MEDIA/NAVIGATION | Phone dependent |
RIDER/PASSENGER INTERCOM | Standard (Passenger Headset Sold Separately) |
VEHICLE INFORMATION SCREEN (AIR TEMPERATURE, OIL PRESSURE AND EITMS) | Standard |
TEXT-TO-SPEECH (TTS) LANGUAGES | Phone dependent |
USB | USB/MTP/iPod/iPhone |
BLUETOOTH | Phone/Media Supported |
ANTI-LOCK BRAKE SYSTEM (ABS) | Included |
ELECTRONIC LINKED BRAKING (ELB) | Included |
TRACTION CONTROL SYSTEM (TCS) | Included |
DRAG-TORQUE SLIP CONTROL SYSTEM (DSCS) | Included |
TIRE PRESSURE MONITORING SYSTEM (TPMS) | Included |
CORNERING ENHANCED ANTI-LOCK BRAKE SYSTEM (C-ABS) | Included |
CORNERING ENHANCED ELECTRONIC LINKED BRAKING (C-ELB) | Included |
CORNERING ENHANCED TRACTION CONTROL SYSTEM (C-TCS) | Included |
